single phase transformer

Product Name

Single-phase Transformer

Product Definition

A single-phase transformer is a stationary electrical device based on the principle of electromagnetic induction, exclusively used in single-phase AC circuits. Its core function is to step up, step down or isolate voltage. As a key piece of equipment for energy conversion in single-phase power supply systems, it is widely applied in low-voltage distribution, residential power supply, small-scale industrial equipment and other scenarios.

Core Structure

1. Iron Core: Manufactured with high-quality cold-rolled grain-oriented silicon steel sheets via laminated processing technology, which reduces hysteresis loss and eddy current loss and improves the efficiency of electromagnetic conversion.

2. Windings: Composed of high-voltage and low-voltage windings, wound with high-strength insulated wires. It features high insulation grade and excellent conductive performance.

3. Housing/Tank: Depending on the insulation and cooling mode, it is divided into oil-immersed tanks (for oil-immersed transformers) and dry-type protective housings (for dry-type transformers), providing dustproof, moisture-proof and mechanical shock protection functions.

4. Insulation System: Adopts high-temperature resistant and aging-resistant insulating materials to ensure the insulation performance and service life of the equipment under rated operating conditions.

5. Accessories: Including wiring terminals, temperature measuring devices, protection devices and other components to ensure the safe and stable operation of the equipment.

Core Advantages

1. Simple and compact structure, small size, light weight, convenient installation and transportation, with low comprehensive cost;

2. Suitable for single-phase power supply networks, with strong compatibility in residential, small commercial and other single-phase power consumption scenarios;

3. Optimized electromagnetic design with low no-load and load losses, high operating efficiency and remarkable energy-saving effect;

4. Flexible design, small size, suitable for installation environments with limited space, meeting diverse on-site installation requirements;

5. Mature manufacturing technology, low failure rate, good operational stability and simple and convenient daily maintenance.

Technical Classification

1. By insulation and cooling mode: Single-phase oil-immersed transformer, single-phase dry-type transformer;

2. By structural form: Single-phase shell-type transformer, single-phase core-type transformer;

3. By application: Single-phase distribution transformer, single-phase isolation transformer, single-phase step-up/step-down transformer.

Core Technical Parameters （customizable）

1. Voltage level: The low-voltage side is commonly 220V/380V, and the high-voltage side is adapted to distribution voltages such as 10kV and 35kV;

2. Rated capacity: 0.5kVA ~ 3150kVA (customizable);

3. Rated frequency: 50Hz/60Hz (globally applicable);

4. Insulation grade: Grade B, Grade F, Grade H (customizable);

5. Protection grade: IP20 ~ IP65 (dry-type type), fully sealed protection (oil-immersed type).

Application Scenarios

1. Residential field: Household power consumption, residential community power distribution, power supply for household appliances, small-scale lighting systems;

2. Commercial field: Power supply for single-phase loads in small shops, convenience stores and office buildings;

3. Industrial field: Small single-phase motors, electronic equipment, laboratory instruments, and small single-phase power supply equipment for mines;

4. Special scenarios: Outdoor temporary power supply, single-phase power distribution in remote areas, and power conversion for mobile equipment.

Customization Services

We support customizing parameters such as voltage level, rated capacity, insulation grade, structural form (shell-type/core-type, oil-immersed/dry-type), protection grade and installation mode according to customer needs, to meet the requirements of personalized power supply scenarios.
